Professional Oven Control Switch T150 Max Working Temp With Good Heat / Fire Resistance

Name: Professional Oven Control Switch T150 Max Working Temp With Good Heat Fire Resistance
Brand: TRIGONPOWER
Price: 1 USD

China Professional Oven Control Switch T150 Max Working Temp With Good Heat / Fire Resistance wholesale

Brand Name : TRIGONPOWER

Model Number : SWH01-002-1

Certification : CE,RoHs

Place of Origin : P.R.CHINA

MOQ : 5000

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 300K SETS / MONTH

Delivery Time : 45 DAYS AFTER ORDER CONFIRMED

Packaging Details : CARTON / PALLET

TYPE : oven temperature control switch

APPERANCE STYLE : ROTARY

CODE : SWH01-002-1

INPUT STYLE : ROTARY KNOB

WORKING FREQUENCY : 50 / 60 HZ

WORKING TEMP. : T150 max

HOUSING MATERIAL : NYLON (PA66)

GLOW WIRE TEST : GWT 850 & GWIT 775 (IEC60335-1 PART 30.2)

FLAME CLASS : UL-94-V0

Contact Now

professional Oven Control Switch T150 Max Working Temp

Description:

When a user operates the switch, he would press, swing or rotate the transfer strength part to input strength to the inside of switch. Then the transfer mechanism would make the movable contact and stationary contact touch or separation to control the circuit’s on-off.

Specification:

TYPE	OVEN CONTROL SWITHC
APPERANCE STYLE	ROTARY
PRODUCT CODE	SWH01-002-1
INPUT STYLE	ROTARY KNOB
OUTPUT STYLE	TERMINAL PIN, FASTON 6.3 X 0.8
OUTPUT QUANTITY	4~12
ELECTRIC PARAMETERS	16(4)A/AC250V
	16(5)A/AC250V
	16(6)A/AC250V
	10(2)A/AC400V
WORKING FREQUENCY	50 / 60 HZ
WORKING TEMP.	T150 max
HOUSING MATERIAL	NYLON (PA66)
GLOW WIRE TEST	GWT 850 & GWIT 775 (IEC60335-1 PART 30.2)
FLAME CLASS	UL-94-V0

Applications:

1. Freestanding Oven

2. Built-in Oven

3. Mini Oven

4. Microwave Oven

5. Gas Cooker

6. Other Home Appliances

Easy to install, clean, and maintenance

We set a elastic snap joint device on the switch, so you could easily install it in the gas cooker or remove it from the gas cooker.

And the surface of the product is very smooth, it is convenient for clean and maintenance.

Good safety properties

1) Good high voltage resistance.

All of the shielding parts have good insulation properties.

COMPONENTS	RAW MATERIAL	VOLTAGE. RESISTANCE
Housing	nylon (PA66)	> AC 600V

2) Good heat and fire resistance.

All of the non-metallic material could pass the heat and fire resistance test of GWT 750 and GWIT 775.
